ARP Billet-Style Rod Bolt Stretch Gauge for Precision Torque Measurement

Description

We highly recommend using a stretch gauge when installing rod bolts and other fastenerswhere it is possible to measure the length of the bolt after tightening. It is the most accurateway to determine the correct pre-load in the rod bolt. Simply follow manufacturer’s instructions, or use the chart on page 30 of this catalog for ARP fasteners. Measure the fastenerprior to starting, and monitor overall length during installation. When the bolt has stretchedthe specified amount, the correct preload, or torque, has been applied. We recommend youmaintain a chart of all rod bolts, and copy down the length of the fastener prior to and afterinstallation. If there is a permanent increase of .001˝ in length or more, or if there is deformation, the bolt should be replaced immediately. Don’t chance it! A sample chart is as follows:ARP offers a highly accurate stretch gauge with a dial indicator that reads in increments of.0005″. Features extra heavy springs for consistent repetition. Comes with a heavy-duty, insulated plastic carrying case for protection. A must for any serious engine builder.
