Ferrea Dual Valve Spring Set (16) for Toyota 3SGE 2.0L BEAMS – S10073

Description

The design and processes on these dual valve springs are optimized to reduce valvetrain harmonics and provide greater stability on high horsepower applications. We use high grade premium super-clean PAC alloy materials and maintain tight tolerances for those unique aftermarket cylinder heads.

Toyota
2.0L – 3SGE ENGINE
Type/Material/Application: Dual Spring – Turbo – Special Alloy
Outside Diameter: 20.8 mm/28.0 mm
Inside Diameter: 15.88 mm/20.8 mm
Seat Pressure: 87 lbs @ 34 mm
Open Pressure: 195 lbs @ 24 mm
Rate Inch: 285 lbs
Coil Bind: 21.5 mm
Max Net Lift: 12.5 mm
This Spring requires Ferrea Titanium Retainer # E11042 and Ferrea Spring Seat Locator # SL1032 (Discard OEM Spring Seat Locator)
