Precision Turbo PT5858 CEA Gen1 Journal Bearing Turbocharger

Description

Street and Race Turbocharger – PT5858 CEA
HP Rating: 620HP
(Horsepower rating are to the crank. Numbers will vary due to size and displacement of engine.)

If you’re looking for a cost effective turbo that can still make a lot of power, the PT5858 CEA® is a great choice. Featuring our revolutionary CEA compressor wheel technology, this turbo offers excellent performance in an easy-to-manage size.
PTE’s PT5858 Turbocharger Features the Following:

• Exclusive CEA (Competition Engineered Aerodynamics) Compressor Wheel Machined from a 2618-Aluminum Forging
• Higher Efficiency and Faster Transient Response for Maximum Power and Performance
• 58mm Inducer Compressor Wheel
• Compressor Cover “Ported S” Compressor Cover 4.0″ Inlet/2.5″ Outlet
• 58mm, 76 Trim Turbine Wheel
• Turbine Housing T3 Inlet Flange with 3″ OD (outer diameter) V-Band Discharge .82 A/R

Precision customers have a history of setting records and getting noticed. They don’t sit in the stands watching the action they’re the ones making it happen. Innovation is a collaborative process and we focus our efforts on you. Get involved and be a part of the action today with PTE.

GEN1 PT5858 Journal Bearing, SP Compressor Cover w/ T3 Inlet/ V-Band Discharge .82 A/R
PN# 10704006119

Recommended Flange and Clamp
Outlet Clamp – 071-1027 (Not Included)
SS Outlet Flange – 074-3012 (Not Included)
